Engineered to handle any emergency, this ambulance prioritises safety of its occupants along with top-notch operational efficiency. It adheres to all statutory norms, including AIS 125 part I norms (National Ambulance Code), ensuring a reliable and safe solution for patient transport. It is also available in the B Type Patient Transport Ambulance (PTA) configuration.
| Certification | Type B (PTA) |
|---|---|
| Model Type | Single Stretcher NAC |
| Seating Capacity | 8+P |
| Cabin Type | Tiltable Cabin |
| Cabin width | 1.8 m |
| GVW | 4995 kg |
| Wheelbase | 2580 mm |
| Engine Type & Displacement (CC) | E366 & 1999 |
| Max Power | 75 kW (~100 hp) @ 3200 Rpm |
| Max Torque | 285 Nm @ 1250-2500 Rpm |
| Transmission | 5+1 R |
| Brake, Front/Rear | Disc |
| Suspension (Front/Rear) | Semi-elliptical / Parabolic suspension with shock absorber and ARB |
| Gradeability (%) | 34% |
| Steering Type | Power, Tilt and Telescopic |
| Overall Length | 5320 mm |
| Overall Width | 2040 +/- 10 mm |
| Overall Height | 2880 mm |
| Compartment internal dimension (LxWxH) | 3375 x 1930 x 1895 mm |
| TCD | 10.3 m |
| Tyre Size | 225/75 R-16 |
| Battery Capacity | 12V, 100 Ah |
| Alternator Power (W) | 700 |
| No of Stretchers / No of doors | 1 |
| Floor type | Antiskid Vinyl |
| Communication Device | Public Announcement System |
| Top speed (km/hr) | 101 |
| Fuel Tank / Adblue Tank | 60 / 19 litres |
